Introduction
Not every RV, campervan, motorhome, or caravan comes equipped with an awning from the factory. However, this does not mean RV owners have to miss out on the comfort and convenience of an outdoor living space.
An RV awning provides much more than shade. It creates additional outdoor living space while helping reduce direct sunlight and providing basic protection from light and rain,which can make long-distance travel and outdoor camping considerably more comfortable.
If your RV didn’t come with a factory-installed awning, choosing a suitable RV aftermarket awning can be an effective way to upgrade your vehicle. With the right assessment of the mounting brackets, vehicle structure, available installation space, awning size, and installation method, it may be possible to complete an aftermarket installation even when the RV was not originally equipped with an awning prep kit.
So, how can you add an awning to an RV without factory preparation? What should you consider before starting a no-awning RV upgrade?
This guide explains the general process of installing an aftermarket RV awning and the key factors to consider before installation.
1. Why Add an Awning to an RV?
An RV awning is one of the most practical upgrades for improving outdoor comfort. For RV owners whose vehicles did not come with a factory awning, an aftermarket awning can provide several important benefits
1. Create More Outdoor Living Space
2. Provide Shade and Basic Rain Protection
3. Upgrade Older or Basic RVs
2. What Should You Check Before Installing an RV Awning?
Before deciding to add an awning to an RV, the most important step is not drilling holes immediately. First, you need to confirm whether the vehicle is suitable for an aftermarket awning installation.
1. Check the Installation Area
First, carefully measure the available mounting width and length on the side of the vehicle and confirm the actual usable installation space.
The installation area needs to provide sufficient room for both the awning body and mounting brackets. At the same time, make sure the selected position does not interfere with:
l Doors, Windows
l Slide-outs
l Exterior lights, Vents
l Storage compartments
l Other exterior accessories
Do not choose an awning size based only on the overall length of the RV. The actual available mounting area is much more important.
2. Check the Vehicle Structure
If the vehicle does not have a factory awning prep kit, structural assessment becomes particularly important.
Factory-prepared RVs may already have reinforced mounting points designed specifically for awnings. However, an RV without an awning prep kit may require additional mounting brackets or reinforcement to distribute the load generated by the awning.
The mounting hardware should be securely attached to a structurally suitable part of the vehicle rather than relying only on a thin exterior panel.
The strength of the mounting area should be considered together with the awning's size, weight, projection, and expected operating conditions.
If the internal structure of the RV wall cannot be clearly identified, professional inspection is recommended before drilling or modifying the vehicle.
3. Consider Awning Size and Weight
The largest awning is not necessarily the most suitable awning for your RV.
A larger awning generally provides more shade coverage, but it can also create greater structural and mechanical loads.
When selecting an RV aftermarket awning, consider factors including:
l Awning width, projection, weight
l Number and position of mounting brackets
l Available mounting space
The goal is to select an awning that provides sufficient coverage while remaining compatible with the vehicle's structure and installation conditions.
4. Check the Electrical Requirements of an Electric Awning
If you choose a 12V electric RV awning, you also need to consider the vehicle's electrical system.
Before installation, confirm that the RV has a suitable 12V power source, wiring, fuse protection, and control system.
For an aftermarket electric awning installation, the wiring should be properly routed and protected from water, friction, heat, and external impact.
All electrical connections should follow the manufacturer's installation instructions. For complex vehicle wiring modifications, professional installation is recommended.
3. General Installation Steps for Adding an Awning to an RV
The exact installation method can vary depending on the awning model, vehicle construction, mounting brackets, and installation conditions. Therefore, always follow the manufacturer's official installation instructions for the specific awning system.
However, a general RV awning installation usually includes the following steps.
Step 1: Measure and Mark the Installation Position
First, determine the appropriate mounting height and horizontal position.
Measure the available installation space and mark the mounting bracket locations. Make sure the awning will not interfere with doors, windows, Slide-outs, exterior lights, or other vehicle accessories.
It is recommended that at least two people work together during positioning and installation. This can improve measurement accuracy and reduce the risk of dropping or damaging the awning.
Step 2: Install the Awning Mounting Brackets
Determine the bracket positions according to the manufacturer's recommended spacing.
Once the position has been confirmed, use hardware suitable for the vehicle structure to secure the mounting brackets.
All brackets should be firmly fixed and correctly aligned. Improper bracket positioning can place additional stress on the awning mechanism and may affect smooth extension and retraction.
For an RV without an awning prep kit, additional brackets or reinforcement may be required depending on the vehicle's construction.
Step 3: Seal and Waterproof the Mounting Points
If installation requires drilling through the exterior surface of the RV, proper waterproofing is essential.
Apply an RV-compatible sealant around mounting holes and other penetrations to help reduce the risk of water entering the vehicle structure.
The sealant should be suitable for the RV exterior material and compatible with the mounting hardware.
Proper sealing is especially important for vehicles that are frequently exposed to rain, humidity, and outdoor conditions.
Step 4: Install the Awning Body
Once the mounting brackets are securely installed, carefully position the awning body onto the mounting system.
Because an RV awning can be relatively long and heavy, two or more people may be required depending on the product size.
After positioning the awning, confirm that the main body is correctly seated on all mounting points before completing the final tightening.
The awning should be properly aligned with the vehicle body to ensure smooth operation.
Step 5: Connect the Electrical System
For a motorized RV awning, connect the 12V power supply according to the manufacturer's wiring instructions.
Make sure the power circuit has appropriate fuse protection and that all electrical connections are properly secured and protected.
Wiring should be routed in a way that minimizes exposure to water, abrasion, heat, and external impact.
If the installation requires significant modifications to the vehicle's existing electrical system, professional assistance is recommended.
Step 6: Perform a Full Function Test
After installation is complete, operate the awning several times through a complete extension and retraction cycle.
Check the following points:
l Smooth extension
l Smooth retraction
l Motor operation
l Arm movement
l Mounting bracket stability
l Electrical connections
l Awning alignment
l Clearance around doors and windows
l Any unusual noise or resistance
For an electric awning, also confirm that the switch, remote control, or other control system operates correctly.
Do not skip the testing stage. Any alignment, mounting, or electrical issue is easier to identify and correct immediately after installation than after the vehicle has returned to the road.
Conclusion: A No-Awning RV Can Still Be Upgraded
Having an RV that did not come with a factory-installed awning does not mean you have to miss out on the benefits of outdoor shade and additional living space.
With a suitable RV aftermarket awning, the correct mounting brackets, accurate measurements, proper waterproofing, and sufficient structural support, many RVs, caravans, campervans, and motorhomes can be upgraded with an aftermarket awning.
A successful add awning to RV project is not simply about choosing the largest awning available. The awning needs to match the vehicle's structure, available mounting space, electrical system, size requirements, and intended usage.
For vehicles without a factory awning prep kit, careful planning is particularly important. Proper attention to mounting structure, bracket positioning, waterproofing, and electrical connections can help create a reliable and practical RV awning upgrade.
Upgrade Your RV with Awnlux
If you are looking for a solution for a no-awning RV upgrade, Awnlux offers a range of RV awning systems designed for caravans, motorhomes, campervans, and other recreational vehicles.
From manual awnings to 12V electric RV awnings, Awnlux focuses on reliable construction, practical installation, and flexible solutions for different RV applications.
Whether you are replacing an old awning or planning to add an awning to an RV that didn't come with one, choosing the right awning system is the first step toward creating a more comfortable and functional outdoor living space.
Learn more about Awnlux RV Awning solutions and explore suitable configurations for your vehicle:
https://www.awnlux.com/
https://awnluxpro.com/
https://www.amazon.com/stores/AWNLUX/page/8AF4E935-DD70-4420-8E57-08EE5CD844F3
Upgrade your RV with a practical aftermarket awning and enjoy more shade, comfort, and outdoor living space on every journey.
